    4CH CCWDM MUX/DEMUX, Compact CWDM Modules

    #5573
    SKU:CCWDM04
    0 Question(s)
    $60.00
    ●Compact Size (Customized)
    ●Unidirectional & Bidirectional WDM
    ●ITU Frequency Grid
    ●Ultra Stable & Highly Reliable
    ●Wave Length: 1270nm ~ 1610nm

    The 10Gtek 4CH CCWDM (Compact CWDM) MUX/DEMUX (Multiplexer/Demultiplexer) is a 4-channel CWDM device with super compact package designed for cost-effective multi-wavelength CWDM network applications.
    It is based on the Thin Film Filter (TFF) technology and operates at four 20nm channel spacing ITU Grid CWDM wavelengths.
    Gigalight provides a series of customized 4CH CCWDM MUX/DEMUX devices packaged in metal box to meet different requirements on port configuration (1310nm/upgrade ports available), fiber type, fiber length, input connector, and output connector.
    10Gtek provides high quality CCWDM with flat channel bandwidth, flexible channel configuration, low insertion loss and high isolation.
    It is designed to upgrade capacity easily as the system grows.
    All 10Gtek products are epoxy-free in the optical path.
